1 # Copyright Bruno da Silva de Oliveira 2003. Use, modification and
   2 # distribution is subject to the Boost Software License, Version 1.0.
   3 # (See accompanying file LICENSE_1_0.txt or copy at
   4 # http:#www.boost.org/LICENSE_1_0.txt)
   5
   6 from declarations import *
   7 from elementtree.ElementTree import ElementTree
   8 from xml.parsers.expat import ExpatError
   9 from copy import deepcopy
  10 from utils import enumerate
  11
  12
  13 #==============================================================================
  14 # Exceptions
  15 #==============================================================================
  16 class InvalidXMLError(Exception): pass
  17
  18 class ParserError(Exception): pass
  19
  20 class InvalidContextError(ParserError): pass
  21
  22
  23 #==============================================================================
  24 # GCCXMLParser
  25 #==============================================================================
  26 class GCCXMLParser(object):
  27     'Parse a GCC_XML file and extract the top-level declarations.'
  28
  29     interested_tags = {'Class':0, 'Function':0, 'Variable':0, 'Enumeration':0}
  30
  31     def Parse(self, filename):
  32         self.elements = self.GetElementsFromXML(filename)
  33         # high level declarations
  34         self.declarations = []
  35         self._names = {}
  36         # parse the elements
  37         for id in self.elements:
  38             element, decl = self.elements[id]
  39             if decl is None:
  40                 try:
  41                     self.ParseElement(id, element)
  42                 except InvalidContextError:
  43                     pass # ignore those nodes with invalid context
  44                          # (workaround gccxml bug)
  45
  46
  47     def Declarations(self):
  48         return self.declarations
  49
  50
  51     def AddDecl(self, decl):
  52         if decl.FullName() in self._names:
  53             decl.is_unique= False
  54             for d in self.declarations:
  55                 if d.FullName() == decl.FullName():
  56                     d.is_unique = False
  57         self._names[decl.FullName()] = 0
  58         self.declarations.append(decl)
  59
  60
  61     def ParseElement(self, id, element):
  62         method = 'Parse' + element.tag
  63         if hasattr(self, method):
  64             func = getattr(self, method)
  65             func(id, element)
  66         else:
  67             self.ParseUnknown(id, element)
  68
  69
  70     def GetElementsFromXML(self,filename):
  71         'Extracts a dictionary of elements from the gcc_xml file.'
  72
  73         tree = ElementTree()
  74         try:
  75             tree.parse(filename)
  76         except ExpatError:
  77             raise InvalidXMLError, 'Not a XML file: %s' % filename
  78
  79         root = tree.getroot()
  80         if root.tag != 'GCC_XML':
  81             raise InvalidXMLError, 'Not a valid GCC_XML file'
  82
  83         # build a dictionary of id -> element, None
  84         elementlist = root.getchildren()
  85         elements = {}
  86         for element in elementlist:
  87             id = element.get('id')
  88             if id:
  89                 elements[id] = element, None
  90         return elements
  91
  92
  93     def GetDecl(self, id):
  94         if id not in self.elements:
  95             if id == '_0':
  96                 raise InvalidContextError, 'Invalid context found in the xml file.'
  97             else:
  98                 msg = 'ID not found in elements: %s' % id
  99                 raise ParserError, msg
 100
 101         elem, decl = self.elements[id]
 102         if decl is None:
 103             self.ParseElement(id, elem)
 104             elem, decl = self.elements[id]
 105             if decl is None:
 106                 raise ParserError, 'Could not parse element: %s' % elem.tag
 107         return decl
 108
 109
 110     def GetType(self, id):
 111         def Check(id, feature):
 112             pos = id.find(feature)
 113             if pos != -1:
 114                 id = id[:pos] + id[pos+1:]
 115                 return True, id
 116             else:
 117                 return False, id
 118         const, id = Check(id, 'c')
 119         volatile, id = Check(id, 'v')
 120         restricted, id = Check(id, 'r')
 121         decl = self.GetDecl(id)
 122         if isinstance(decl, Type):
 123             res = deepcopy(decl)
 124             if const:
 125                 res.const = const
 126             if volatile:
 127                 res.volatile = volatile
 128             if restricted:
 129                 res.restricted = restricted
 130         else:
 131             res = Type(decl.FullName(), const)
 132             res.volatile = volatile
 133             res.restricted = restricted
 134         return res
 135
 136
 137     def GetLocation(self, location):
 138         file, line = location.split(':')
 139         file = self.GetDecl(file)
 140         return file, int(line)
 141
 142
 143     def Update(self, id, decl):
 144         element, _ = self.elements[id]
 145         self.elements[id] = element, decl
 146
 147
 148     def ParseUnknown(self, id, element):
 149         name = '__Unknown_Element_%s' % id
 150         decl = Unknown(name)
 151         self.Update(id, decl)
 152
 153
 154     def ParseNamespace(self, id, element):
 155         namespace = element.get('name')
 156         context = element.get('context')
 157         if context:
 158             outer = self.GetDecl(context)
 159             if not outer.endswith('::'):
 160                 outer += '::'
 161             namespace = outer + namespace
 162         if namespace.startswith('::'):
 163             namespace = namespace[2:]
 164         self.Update(id, namespace)
 165
 166
 167     def ParseFile(self, id, element):
 168         filename = element.get('name')
 169         self.Update(id, filename)
 170
 171
 172     def ParseVariable(self, id, element):
 173         # in gcc_xml, a static Field is declared as a Variable, so we check
 174         # this and call the Field parser.
 175         context = self.GetDecl(element.get('context'))
 176         if isinstance(context, Class):
 177             self.ParseField(id, element)
 178             elem, decl = self.elements[id]
 179             decl.static = True
 180         else:
 181             namespace = context
 182             name = element.get('name')
 183             type_ = self.GetType(element.get('type'))
 184             location = self.GetLocation(element.get('location'))
 185             variable = Variable(type_, name, namespace)
 186             variable.location = location
 187             self.AddDecl(variable)
 188             self.Update(id, variable)
 189
 190
 191     def GetArguments(self, element):
 192         args = []
 193         for child in element:
 194             if child.tag == 'Argument':
 195                 type = self.GetType(child.get('type'))
 196                 type.default = child.get('default')
 197                 args.append(type)
 198         return args
 199
 200
 201     def GetExceptions(self, exception_list):
 202         if exception_list is None:
 203             return None
 204
 205         exceptions = []
 206         for t in exception_list.split():
 207             exceptions.append(self.GetType(t))
 208
 209         return exceptions
 210
 211
 212     def ParseFunction(self, id, element, functionType=Function):
 213         '''functionType is used because a Operator is identical to a normal
 214         function, only the type of the function changes.'''
 215         name = element.get('name')
 216         returns = self.GetType(element.get('returns'))
 217         namespace = self.GetDecl(element.get('context'))
 218         location = self.GetLocation(element.get('location'))
 219         params = self.GetArguments(element)
 220         incomplete = bool(int(element.get('incomplete', 0)))
 221         throws = self.GetExceptions(element.get('throw', None))
 222         function = functionType(name, namespace, returns, params, throws)
 223         function.location = location
 224         self.AddDecl(function)
 225         self.Update(id, function)
 226
 227
 228     def ParseOperatorFunction(self, id, element):
 229         self.ParseFunction(id, element, Operator)
 230
 231
 232     def GetHierarchy(self, bases):
 233         '''Parses the string "bases" from the xml into a list of tuples of Base
 234         instances. The first tuple is the most direct inheritance, and then it
 235         goes up in the hierarchy.
 236         '''
 237
 238         if bases is None:
 239             return []
 240         base_names = bases.split()
 241         this_level = []
 242         next_levels = []
 243         for base in base_names:
 244             # get the visibility
 245             split = base.split(':')
 246             if len(split) == 2:
 247                 visib = split[0]
 248                 base = split[1]
 249             else:
 250                 visib = Scope.public
 251             decl = self.GetDecl(base)
 252             if not isinstance(decl, Class):
 253                 # on windows, there are some classes which "bases" points to an
 254                 # "Unimplemented" tag, but we are not interested in this classes
 255                 # anyway
 256                 continue
 257             base = Base(decl.FullName(), visib)
 258             this_level.append(base)
 259             # normalize with the other levels
 260             for index, level in enumerate(decl.hierarchy):
 261                 if index < len(next_levels):
 262                     next_levels[index] = next_levels[index] + level
 263                 else:
 264                     next_levels.append(level)
 265         hierarchy = []
 266         if this_level:
 267             hierarchy.append(tuple(this_level))
 268         if next_levels:
 269             hierarchy.extend(next_levels)
 270         return hierarchy
 271
 272
 273     def GetMembers(self, member_list):
 274         # members must be a string with the ids of the members
 275         if member_list is None:
 276             return []
 277         members = []
 278         for member in member_list.split():
 279             decl = self.GetDecl(member)
 280             if type(decl) in Class.ValidMemberTypes():
 281                 if type(decl) is str:
 282                     print decl
 283                 members.append(decl)
 284         return members
 285
 286
 287     def ParseClass(self, id, element):
 288         name = element.get('name')
 289         abstract = bool(int(element.get('abstract', '0')))
 290         location = self.GetLocation(element.get('location'))
 291         context = self.GetDecl(element.get('context'))
 292         incomplete = bool(int(element.get('incomplete', 0)))
 293         if isinstance(context, str):
 294             class_ = Class(name, context, [], abstract)
 295         else:
 296             # a nested class
 297             visib = element.get('access', Scope.public)
 298             class_ = NestedClass(
 299                 name, context.FullName(), visib, [], abstract)
 300         class_.incomplete = incomplete
 301         # we have to add the declaration of the class before trying
 302         # to parse its members and bases, to avoid recursion.
 303         self.AddDecl(class_)
 304         class_.location = location
 305         self.Update(id, class_)
 306         # now we can get the members and the bases
 307         class_.hierarchy = self.GetHierarchy(element.get('bases'))
 308         if class_.hierarchy:
 309             class_.bases = class_.hierarchy[0]
 310         members = self.GetMembers(element.get('members'))
 311         for member in members:
 312             if type(member) is str:
 313                 print member
 314             class_.AddMember(member)
 315
 316
 317     def ParseStruct(self, id, element):
 318         self.ParseClass(id, element)
 319
 320
 321     FUNDAMENTAL_RENAME = {
 322         'long long int' : 'boost::int64_t',
 323         'long long unsigned int' : 'boost::uint64_t',
 324     }
 325
 326     def ParseFundamentalType(self, id, element):
 327         name = element.get('name')
 328         name = self.FUNDAMENTAL_RENAME.get(name, name)
 329         type_ = FundamentalType(name)
 330         self.Update(id, type_)
 331
 332
 333     def ParseArrayType(self, id, element):
 334         type = self.GetType(element.get('type'))
 335         min = element.get('min')
 336         max = element.get('max')
 337         array = ArrayType(type.name, type.const, min, max)
 338         self.Update(id, array)
 339
 340
 341     def ParseReferenceType(self, id, element):
 342         type = self.GetType(element.get('type'))
 343         expand = not isinstance(type, FunctionType)
 344         ref = ReferenceType(type.name, type.const, None, expand, type.suffix)
 345         self.Update(id, ref)
 346
 347
 348     def ParsePointerType(self, id, element):
 349         type = self.GetType(element.get('type'))
 350         expand = not isinstance(type, FunctionType)
 351         ref = PointerType(type.name, type.const, None, expand, type.suffix)
 352         self.Update(id, ref)
 353
 354
 355     def ParseFunctionType(self, id, element):
 356         result = self.GetType(element.get('returns'))
 357         args = self.GetArguments(element)
 358         func = FunctionType(result, args)
 359         self.Update(id, func)
 360
 361
 362     def ParseMethodType(self, id, element):
 363         class_ = self.GetDecl(element.get('basetype')).FullName()
 364         result = self.GetType(element.get('returns'))
 365         args = self.GetArguments(element)
 366         method = MethodType(result, args, class_)
 367         self.Update(id, method)
 368
 369
 370     def ParseField(self, id, element):
 371         name = element.get('name')
 372         visib = element.get('access', Scope.public)
 373         classname = self.GetDecl(element.get('context')).FullName()
 374         type_ = self.GetType(element.get('type'))
 375         static = bool(int(element.get('extern', '0')))
 376         location = self.GetLocation(element.get('location'))
 377         var = ClassVariable(type_, name, classname, visib, static)
 378         var.location = location
 379         self.Update(id, var)
 380
 381
 382     def ParseMethod(self, id, element, methodType=Method):
 383         name = element.get('name')
 384         result = self.GetType(element.get('returns'))
 385         classname = self.GetDecl(element.get('context')).FullName()
 386         visib = element.get('access', Scope.public)
 387         static = bool(int(element.get('static', '0')))
 388         virtual = bool(int(element.get('virtual', '0')))
 389         abstract = bool(int(element.get('pure_virtual', '0')))
 390         const = bool(int(element.get('const', '0')))
 391         location = self.GetLocation(element.get('location'))
 392         throws = self.GetExceptions(element.get('throw', None))
 393         params = self.GetArguments(element)
 394         method = methodType(
 395             name, classname, result, params, visib, virtual, abstract, static, const, throws)
 396         method.location = location
 397         self.Update(id, method)
 398
 399
 400     def ParseOperatorMethod(self, id, element):
 401         self.ParseMethod(id, element, ClassOperator)
 402
 403
 404     def ParseConstructor(self, id, element):
 405         name = element.get('name')
 406         visib = element.get('access', Scope.public)
 407         classname = self.GetDecl(element.get('context')).FullName()
 408         location = self.GetLocation(element.get('location'))
 409         params = self.GetArguments(element)
 410         ctor = Constructor(name, classname, params, visib)
 411         ctor.location = location
 412         self.Update(id, ctor)
 413
 414
 415     def ParseDestructor(self, id, element):
 416         name = element.get('name')
 417         visib = element.get('access', Scope.public)
 418         classname = self.GetDecl(element.get('context')).FullName()
 419         virtual = bool(int(element.get('virtual', '0')))
 420         location = self.GetLocation(element.get('location'))
 421         des = Destructor(name, classname, visib, virtual)
 422         des.location = location
 423         self.Update(id, des)
 424
 425
 426     def ParseConverter(self, id, element):
 427         self.ParseMethod(id, element, ConverterOperator)
 428
 429
 430     def ParseTypedef(self, id, element):
 431         name = element.get('name')
 432         type = self.GetType(element.get('type'))
 433         context = self.GetDecl(element.get('context'))
 434         if isinstance(context, Class):
 435             context = context.FullName()
 436         typedef = Typedef(type, name, context)
 437         self.Update(id, typedef)
 438         self.AddDecl(typedef)
 439
 440
 441     def ParseEnumeration(self, id, element):
 442         name = element.get('name')
 443         location = self.GetLocation(element.get('location'))
 444         context = self.GetDecl(element.get('context'))
 445         incomplete = bool(int(element.get('incomplete', 0)))
 446         if isinstance(context, str):
 447             enum = Enumeration(name, context)
 448         else:
 449             visib = element.get('access', Scope.public)
 450             enum = ClassEnumeration(name, context.FullName(), visib)
 451         self.AddDecl(enum)
 452         enum.location = location
 453         for child in element:
 454             if child.tag == 'EnumValue':
 455                 name = child.get('name')
 456                 value = int(child.get('init'))
 457                 enum.values[name] = value
 458         enum.incomplete = incomplete
 459         self.Update(id, enum)
 460
 461
 462
 463 def ParseDeclarations(filename):
 464     'Returns a list of the top declarations found in the gcc_xml file.'
 465
 466     parser = GCCXMLParser()
 467     parser.Parse(filename)
 468     return parser.Declarations()
 469
 470
 471 if __name__ == '__main__':
 472     ParseDeclarations(r'D:\Programming\Libraries\boost-cvs\boost\libs\python\pyste\example\test.xml')
